SECTION 00 - GENERAL INFORMATION
00-13
PIPE THREAD FITTING TORQUE
Thread Size Torque (Maximum)
1/8″ – 27 13 N⋅m (10 ft. lbs.)
1/4″ – 18 16 N⋅m (12 ft. lbs.)
3/8″ – 14 22 N⋅m (16 ft. lbs.)
1/2″ – 14 41 N⋅m (30 ft. lbs.)
3/4″ – 14 54 N⋅m (40 ft. lbs.)
Before installing and tightening pipe fittings, clean
the threads with a clean solvent or Loctite cleaner
and apply sealant Loctite no. 567 for all fittings
including stainless steel or no. 565 for most metal
fittings. For high filtration/zero contamination
systems use no. 545.
LUBRICANTS AND COOLANTS
Application New Holland Part Number Specification
Gearboxes 1 qt – #9613295
2.5 gal – #9613294
4 L – #9613375
SAE 80W-90
Final Drive chain case 1 qt – #9613313
2.5 gal – #9613314
1 L – #9613358
20 L – #9613360
API Service SH–CG4 10W-30
Hydraulic/Transmission 1 qt – #9613313
2.5 gal – #9613314
1 L – #9613358
20 L – #9613360
API Service SH–CG4 10W-30
All lubrication fittings Tube – #9613310 High viscosity lithium base grease
Engine 1 qt – #9613313
2.5 gal – #9613314
1 L – #9613358
20 L – #9613360
API Service SH-CG4 10W-30
Refer to Operator’s Manual for
Temperature/Oil Usage Chart
Cooling System 1 gal – #FGCC2701DS Antitreeze/Water 50/50
Mixture (Ethylene Glycol)
SEALANTS
Description New Holland Part Number Typical Applications Strength Color
Thread Lock L22200 (222)
L24231 (242)
L29000 (290)
L26231 (262)
Small Screws/Hardware
Nuts and Bolts
Wicking Type
Nuts and Bolts
Low
Medium
Medium
High
Purple
Blue
Green
Red
Thread Sealants L54531 (545)
L56531 (565)
L56747 (567)
Hydraulic/Pneumatic
Pipe Sealant
Pipe Sealant
Non-Fouling
Controlled Strength
High Temperature
Silicones L81724 (3.5 oz. tube)
L58775 (10.2 oz. cartridge)
L82180 (3.35 oz. tube)
L59875 (10.2 oz. cartridge)
Ultra Blue RTV Gasket
Ultra Blue RTV Gasket
Ultra Blue RTV Gasket
Ultra Blue RTV Gasket
Non-corrosive
Non-corrosive
Non-corrosive
Non-corrosive
Blue
Blue
Black
Black
