9
7. Working in a diagonal sequence tighten each bolt by a half turn
before moving on to the next allowing each bolt to be tightened
evenly, until all are tight and the handlebar will not rotate in the
stem. Ensure the handlebars are perpendicular to the front wheel.
8. To avoid damage during shipping pedals are not pre-
installed onto the cranks, so you will need the 15mm
spanner and pedals from the box.
9. The pedals will look similar but one is intended for the
Right crank and one for the Left crank. Each pedal
will either have an R for Right and L for left.
10. Using the 15mm spanner attach the pedals to the crank arms:
- The Right pedal should be tightened in a clockwise
direction.
- The Left pedal should be tightened anticlockwise
direction.
11. The thread on the pedals should easily be found. If not
remove the pedal, realign and try again. Never use
force to engage the thread.
