Newlec NLPH200E - Page 9

Instructions
Newlec Helpline: 0800 783 6909
‘
A’
287
‘B’
Minimum
mounting
clearance
Minimum mounting clearance
138
Fig. 2
WARNING:
The wall bracket should be handled
with care as it may have sharp
edges that may cause cuts and
lacerations.
Fi. 1
300mm
150mm
(min)
‘E’
Shelf / Obstruction
Minimum front clear-
ance
*Please note correct product
orientation is with controller
facing top right side only
150mm
(min)
Fi. 4
‘C’
150mm (min)
150mm (min)
‘D’
Minimum mounting clearance
150mm (min)
Fi. 3
9
