6.1 Depth of the seat
Note: To avoid a risk of injury it is recommended to be two persons. A person to hold the backrest and a second person to screw.
To adjust the seat depth it must:
- Remove the seat cushion
- Old the backrest
- Unscrew the screws 1 and 2 fixing the brackets with armrests (Retain the nuts under the
base plate) and the 2 bolts of the lower mounting of the cylinder or adjustment bar.
- Pull the 2 brackets of armrest the same distance toward the front or rear to adjust the
depth.
- Refer to paragraph 6.2 to determine the position of the lower securing the cylinder or
the adjusting bar of the folder.
- Retighten the screws, taking care to always have at least 1 hole free between the screws
1 and 2.
Note: The back of the brackets of the armrest should never exceed the rear of the base plate on the wich they are fixed.
