Height adjustment of the footrest:
The height of the footrest can be adjusted by step of 2 cm).
To adjust the height of the footrest you must:
- Unscrew the screws #1 (Retain the nuts at the rear of the gallows)
- Place the bracket for the footrest to the desired height
- Retighten the screws #1
Adjusting the tilt of the legrest:
To change the tilt of the legrest it must:
- Unscrew the nut on the set screw of bute #1 and remove
- Raise the legrest to the desired angle
- Replace the screw #1 in port 2 closer to the desired angle
- Replace the nut on the screw #1 and retighten
