REPLACEMENT PARTS
List Part Numbers – Newmac Classic II Mobile
Model NCM120 Wood Heater
KEY NO.
PART NO. DESCRIPTION
1 2140050 Draft Control Knob
2 2210255 High/Low Label
3 2160006 Cotter Pin 1/16 x ¾”
5 2220006 7/8” x 3/8” Diameter Spring
6 3090359 Thermostat Stop
7 3090358 Thermostat Standoff
8 3090359 Thermostat Stop
9 2220007 Bi Metal Thermostat Spring
10 4110535 Cast Pipe Connector Painted
11 2220013 Hinges 1 ½” x 1 ½”
12 4110558 Top Louvre Panel (Painted)
14 4060317 Baffle Supports
15 3080177 Baffle
16 4110557 Rear Panel (Painted)
17 4110545 Casing Door (Painted)
18 4110561 Wooden Knobs, Stained brown
19 2220016 Roller Catch
20 3120168 Rear Brick Spacer
21 2030011 Split Brick
22 4110544 Casing End (Painted)
23 4110547 Screen Assembly (Painted)
24 2210258 Classic II Mobile Label
25 4110556 Front Bottom Louvre Panel (Painted)
26 4110551 Draft Door
27 3070017 Top Damper Chain
28 4110560 Cast Air Inlet
29 2170022 Cast Iron Grates
30 4060314 Top Brick Rack
31 4060315 Bottom Brick Rack
32 3030014 Front Liners
33 2160011 7/32 x 3 ¼ “ Steel Door Pins
34 4160126 Firedoor C/W Rope Gasket Glued
35 2080080 Door Gasket 42” Rope
36 4160127 Ashdoor C/W Rope Gasket Glued
37 2080080 Door Gasket 28.8” Rope
38 4010315 Ashpan
39 4110539 Door Handle
40 4110561 Wooden Handles, Stained Brown
41 4110531 Door Catch Painted (Only 1 Replaceable)
42 4110546 Casing Door End Frame (Painted)
43 4110555 Firebox Assembly (Painted)
44 See # 16 Spot Welded to Rear Panel
45 3160385 Ash Pan Support
46 4010325 Combustion Air Tube Assembly (Required for Mobile Home)
47 Floor Anchor Brackets (Application – Order Separately)
NOTE: Some parts available as complete assemblies only.
