Nexa DORNIER DO-27 - Rudder Control Horn; Tail Wheel

Note: The slots for the control horn
installation pre- cut at factory.
Control horn
...........2
3x12mm screw
.......................2
......................1
1.5mm
3x12mm screw
Collar
CA
DORNIER DO-27
5-Rudder control horn
WARNING! Securely glue together.
If coming off during flights, you lose control
of your airplane which leads to accidents !
DORNIER DO-27
6-Tail wheel
2mm
FUSELAGE
..................2
3x12mm bolt
...........2
