Nexa ZRT-106 - Page 3

Z-Wave Plus
TM
Info
Role Type
Node Type
Installer Icon
User Icon
Slave Sleeping
Listening
Z-Wave Plus
TM
node
Generic_Thermostat
Generic_Thermostat
Association Command Class
Group
Max Node
1
1
Version
Protocol Library
3 (Slave_Enhance_232_Library)
Protocol Version
6.04(6.81.03)
Manufacturer
Manufacturer ID
Product Type
Product ID
0x0060
0x0015
0x0001
AGI (Association Group Information) Table
Group
Profile
Command Class & Command (List) N bytes
Group Name(UTF-8)
1
General
Battery Report,
Device Reset Locally Notification,
Notification Report
Sensor Multilevel Report
Thermostat Mode Report
Thermostat Setpoint Report
Protection Report
Clock Report
Lifeline
Notification
Event
Type
Event
Event
Parameter
Length
Event
Parameter
The power is applied for the first time
0x08
0x01
0x00
Battery
Battery Report (value)
Description
20~100
Battery Level %
0xFF
Low Battery
Command Classes
The module supports Command Classes including…
 COMMAND_CLASS_ZWAVEPLUS_INFO_V2
 COMMAND_CLASS_ASSOCIATION_V2
 COMMAND_CLASS_ASSOCIATION_GRP_INFO
 COMMAND_CLASS_TRANSPORT_SERVICE_V2
 COMMAND_CLASS_VERSION_V3
 COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2
 COMMAND_CLASS_DEVICE_RESET_LOCALLY
 COMMAND_CLASS_POWERLEVEL
 COMMAND_CLASS_SECURITY
 COMMAND_CLASS_SECURITY_2
 COMMAND_CLASS_SUPERVISION
 COMMAND_CLASS_FIRMWARE_UPDATE_MD_V4
 COMMAND_CLASS_BATTERY
 COMMAND_CLASS_NOTIFICATION_V8
 COMMAND_CLASS_CONFIGURATION
 COMMAND_CLASS_SENSOR_MULTILEVEL
 COMMAND_CLASS_APPLICATION_STATUS
 COMMAND_CLASS_THERMOSTAT_MODE_V3
 COMMAND_CLASS_THERMOSTAT_SETPOINT_V3
 COMMAND_CLASS_PROTECTION
 COMMAND_CLASS_CLOCK
Basic Command Class
 Basic Get: Command to inquire the status of the device.
 Basic Report: Report the status of the device.
 Basic Set: Set the status of the device.
Basic Set Value
Description
0x00
Energy Heat
0x0F
Off
0xFF
Heat
Z-Wave Configuration
1. Temperature Auto Report period setting
Parameter Number
Size
Range
Default
1
2
1~255 (min)
120mins
2. Temperature offset for internal sensor
Parameter Number
Size
Range
Default
2
1
-80~+80 Offsets the
measured temperature by
-8.0℃~+8.0℃
00=0.0℃ Offset
3. Maximum Set point value
Parameter Number
Size
Range
Default
3
1
5~35 for 5℃~35℃
35=35℃
4. Minimum Set point value
Parameter Number
Size
Range
Default
4
1
5~35 for 5℃~35℃
5=5℃
5. Frost protection temperature
Parameter Number
Size
Range
Default
5
1
5~15 for 5℃~15℃
5=5℃
6. Open window detect function
Parameter Number
Size
Range
Default
6
1
0: Disable
1: Enable
0
7. Open window detect time period
Parameter Number
Size
Range
Default
7
1
2~30 (min)
15mins
8. Open window detect temperature drop setting
Parameter Number
Size
Range
Default
8
1
4=2℃ , 5=2.5℃
6= 3℃, 7=3.5℃, 8=4℃
4=2℃
9. Open window detect delay time select
Parameter Number
Size
Range
Default
9
1
10~60 (min)
30mins
10. Manual Override takeover period
