10
2. Wireless setting (please parse GPRS/CDMA SIM card)
Input APN1：set APN1
Input APN2：set APN2
If needing users： 0-No 1-Yes
User name 1： input user name 1
User password 1：input user password 1
User name 2：input user name 2
User password 2：input user password 2
Host IP1：input Host IP1
Host port1：input host port1
Host IP2：input Host IP2
Host port2：input Host port2
Select APN：select using APN（0 or 1）
Dynamic IP：set if select dynamic IP
Automatic switch：set if automatically switch to dial-up or Ethernet
Link method：select link method 0-long link 1-short link
Calling times：set calling times
4.TPDU setting：banking cards TPDU, total 10 bits, the first 2 bits are
TPDU ID, generally they are 60, and the middle 4 bits are the target
address of TPDU, the last 4 bits are source address of ；
3. Transaction functions setting:
shield transaction：set function of shield transaction to stop
transaction
Chargeback setting：set if automatic chargeback after settlement
Tip setting： set if support tip, if support, then you should set
the proportion of tip
Resend times: set if fail to do transaction, it will resend automatically, and
press “CLR” to delete previous data and input the required
number.
Print pages: set pages number of printing receipts
Maximum transaction:set if storing maximum transaction times at this batch, when
transaction times of this batch ≥ the setting number, system will
remind settlement, if transaction number is 1~500, then the default
is 300 transactions.
Other parameter：input card No. by hand: set if support transaction by inputting
card No. by hand
Offline upload: set offline transaction if uploads before next
online transaction or settlement
Password keypad: if having password keypad
Completion methods of Magnetic card pre-authorization：
set completion methods of magnetic card
Transaction functions setting
1. shield transaction 5.print page number
2.chargeback setting 6.maximum transaction
3.tip setting 7. Other parameter
4.resend times 8.IC card parameter
To Next Page
