NOTE: 20 pound (9.0 kgs), 5 Gallon (18.9 liters) LPG Tank is not supplied
Tools Needed:
Phillips Head Screwdriver
Two Adjustable Opening Wrenches
Spray Bottle of Soapy Water (To check for leaks)
Parts supplied:
Tank Hook (1)Post (1)
LP Gas regulator with Hose (1)Heater Head With PVC Hose Assembly (1)
Gas Tank Enclosure Assembly (1)Reflector (3)
Gas Tank Supporting (1)Reflector Plate (1)
4
TOOLS AND PARTS NEEDED FOR ASSEMBLY
For Service Questions Replacement parts or other assistance, Please call Nexgrill Customer Service
Hotline at: Nexgrill Industries, Inc
5270 Edison Avenue, Chino, CA 91710
1-866-984-7455
PRECAUTIONS
ØDo not use this patio heater in an explosive atmosphere.
Keep heater away from areas where gasoline or other
flammable liquids or vapors are stored.
ØPrior to use, check for damaged parts such as hoses
regulator, or burner.
ØDo not attempt to alter unit in any manner. EXAMPLE:
using the heater without the top canopy reflector or radiant
screen. Do not shorten the burner post assembly.
ØHeater must always be placed on a solid and level surface.
ØAlways maintain proper clearance to combustible materials.
Top 800mm, Side 1300mm.
ØAlways assure there is ample fresh air ventilation for
outdoors use ONLY.
ØNever replace or substitute the regulator with any regulator
other than the factory suggested replacement.
ØDo not clean heater with cleaners that are combustible or
corrosive
ØDo not paint radiant screen, control panel or top canopy
reflector.
ØMore frequent cleaning may be required as necessary. It is
imperative that control compartment, burners and circulating
air passage of the heater be kept clean.
ØAll leak tests should be done with a soapy solution NEVER
USE AN OPEN FLAME TO CHECK FOR LEAKS.
ØThe LP tank should be turned off when the heater is not in use
ØAt least once a year, the unit should be inspected for the presence
of spiders, spider webs or other insects. The burner area is a
common spider haven and can damage the heater and render it
unsafe for use, Check the heater immediately if any of the
following exists:
1. The smell of gas in conjunction with extreme yellow tipping of
the burner flames
2. The heater does nor reach temperature.
3. The burner makes a popping noise during use (a slight popping
noise is normal when the burner is extinguished).
ØThe LP regulator/ hose assembly should be located out of
pathways Where people may trip over it or in area where the hose
will not be subject to accidental damage.
ØChildren and adults should be aware of hazards of high surface
temperature and should stay away to avoid burns of clothing
ignition.
ØYoung children should be carefully supervised when they are in
the area of the heater.
ØClothing or other flammable material should not be hung from the
heater, or placed on or near the heater.
ØWhen applicable, visually checking portions of the hose assembly
located within the confines of the heater post
ØThe cylinder must be provided with a shut off valve terminating in
an LP-Gas supply cylinder valve outlet specified
