ITEM# MD1008
OPERATION OF LCD
Note:
Before using, please be sure Audio and Video RCAs are connected, yellow
plug connects with the video signal 1, and green plug connects with video
signal 2, white plug link with left audio channel, red plug link with right audio
channel.
1. Press “Open” to release the LCD; adjust the viewing angle by pushing it back.
2. Press the Power button to turn the LCD on or off, when the LCD is off the
bottom is blue, if on the buttons will illuminate.
3. Press “menu” at the bottom and work with these buttons to adjust the
screen brightness, saturation , contrast, tint , sharpness, OSD H-Position,
original factory settings, OSD level position, OSD vertical position, OSD
waiting time, self-searching channel (TV mode) and exit menu.
4. V1/V2 bottom can exchange the Video 1 and Video 2.
5. Infrared wireless headphones
• The receiving area of the headphones is 8m and 45 degree angle.
• Before using the head phone, please be sure they are powered on.
Make sure the volume is not loud or it will cause damage to hearing.
6. The reading lamp switch is located at the bottom and can be powered on or
off from there.
9
