SPECIFICATION
GENERAL
Supply Voltage DC 14.4V. Negative Ground
Current Consumption Max.15A
Power Output 40W atts X 4ch.
Number of channels 2 STEREO channels.
Unit Dimensions 178[W] X 164[D] X 50[H] mm.
FM SECTION
Frequency range 87.5MHz -107.9MHz
Effective sensitivity 3uV.
I.F Frequency 10.7MHz.
AM SECTION
Frequency range 530KHz - 1710KHz
Effective sensitivity 40dB.
I.F Frequency 450KHz
RCA LINE OUT (OPTION)
Output 1200mV @ CD MAX.
CD PLAYER
System MP3 Audio System.
Suitable CDs MP3, WMA, CD, CD-R, CD-RW Disc
Frequency characteristics
20Hz-100Hz ≤ 5dB
10KHz-20KHz ≤ 5dB.
S/N Ratio to CD 50dB [1KHz]
E 12
