Nexus 21 L-85 - Page 17

9a. Connect Cable #1 to the Lower Column Pigtail on the CB Side and Cable #2 to the Lower Column Pigtail on the AV Side.
9b. Pull any slack on these cables down through their respective cable tracks then hang it behind the angled flanges on the Rear Support.
9c. Route Cable #2 behind the Lower Column Assemblies and to the CB Side so you can connect it to your Control Box later.
17
