Nexus 21 L-85 - Page 24

#3
#4
14a. Temporarily disconnect Cable #3 and #4 from the Upper Assembly, then feed them up through the L-shaped end on one of the Upper Cable Tracks.
14b. Attach the L-Shaped end of this Upper Cable Track to the top surface of the Center Riser on the CB Side using (2) M6 x 10 BHMS.
14c. Attach the other end of the Upper Cable Track to the CB Side of the Upper Assembly using (2) M6 x 10 BHMS.
24
x4
