Nexus 21 L-85 - Page 26

AV Cables
16a. Feed the previously managed AV Cables on the AV Side, up through the remaining Upper Cable Track.
16b. Attach the L-shaped end of the Upper Cable Track to the top surface of the Center Riser on the AV Side using (2) M6 x 10 BHMS.
16c. Attach the other end of the Upper Cable Track to the AV Side of the Upper Assembly using (2) M6 x 10 BHMS.
26
x4
