Parts & Hardware List
38”
37”
36”
35”
34”
33”
29”
30”
31”
32”
28”
27”
26”
25”
24”
23”
22”
21”
TV Mounting Template
Power Cord Control Kit (see pg. 41)
Hardware Pack
(See Contents List Below)
TV Mounting Template
5
M5 x 10 FHMS (12)
M6 x 12 FHMS (20)
M6 x 20 FHMS (8) M6 x 10 BHMS (22) M6 x 20 BHMS (2)
#8 X 3/4” FHWS (10)
#10 X 1 3/4” FHWS (2)
#10 X 3/4” THWS (21) M6 Wing Nut (4) M6 Lock Washer (4)
1/4” Flat Washer (4) Lid Attachment Pin (2) 3mm Hex Key (1) 4mm Hex Key (1) Large Assorted TV Hardware
Zip Tie (12)
Snakeskin Tie (2)
Hardware Pack Contents:
*Large Assorted TV Hardware accomodates most TV’s but additional hardware may be necessary to mount certain TV’s.
