Nexus 21 L-85 - Page 9

2a. Slide Lower Column Clamps around the Lower Column Assemblies with the holes on the outside, then seat the pigtails as shown above for each column.
2b. Slide Lower Column Assemblies onto Base Mount Studs with the Pigtails facing outwards.
2c. Maneuver Lower Column Assemblies to place tongue of the Lower Column Clamps into their respective slots on the Rear Support.
9
Tongue
Pigtail
