DMX Values
53Ch
Channel
Function
Value
Percent/Setting
1
Red 1
000 ó 255
0–100%
Warm White 1
When values 011–020 in CH. 53 are
activated
2
Green 1
000 ó 255
0–100%
Cool White 1
When values 011–020 in CH. 53 are
activated
3
Blue 1
000
ó
255
0–100%
4
Red 2
000 ó 255
0–100%
Warm White 2
When values
011
–
020
in CH. 53 are
activated
5
Green 2
000 ó 255
0–100%
Cool White 2
When values 011–020 in CH. 53 are
activated
6
Blue 2
000
ó
255
0–100%
7
Red 3
000 ó 255
0–100%
Warm White 3
When values 011–020 in CH. 53 are
activated
8
Green 3
000 ó 255
0–100%
Cool White 3
When values 011–020 in CH. 53 are
activated
9
Blue 3
000
ó
255
0–100%
10
Red 4
000 ó 255
0–100%
Warm White 4
When values 011–020 in CH. 53 are
activated
11
Green 4
000 ó 255
0–100%
Cool White 4
When values 011–020 in CH. 53 are
activated
12
Blue 4
000
ó
255
0–100%
13
Red 5
000 ó 255
0–100%
Warm White 5
When values 011–020 in CH. 53 are
activated
14
Green 5
000 ó 255
0–100%
Cool White 5
When values 011–020 in CH. 53 are
activated
15
Blue 5
000
ó
255
0–100%
16
Red 6
000 ó 255
0–100%
Warm White 6
When values 011–020 in CH. 53 are
activated
17
Green 6
000 ó 255
0–100%
Cool White 6
When values 011–020 in CH. 53 are
activated
18
Blue 6
000
ó
255
0–100%
19
Red 7
000 ó 255
0–100%
Warm White 7
When values 011–020 in CH. 53 are
activated
