Nexus™ 4x4 QRG EN
9
Main Level
Programming Levels
Description
Info
Fixture Hours
Shows total operating hours
Version
Shows software version
IP Address
Shows IP address
Device ID
Shows ID number
DMX Address
001–512
Sets DMX start channel for DMX mode
DMX Channel
3Ch
Sets DMX personality for DMX, Art-Net™
mode, and Kling-Net modes
5Ch
9Ch
48Ch
53Ch
Master/Slave
Master
Sets Master mode
Slave
Sets Slave mode
White
R
125–255
Sets the color mix that will be white
G
B
Fan Speed
Auto
Sets fan to slow down when product is cool
High
Sets fan to run continuously at high speed
Temperature
Shows the product’s internal temperature
Ethernet Settings Protocol
Kling-Net
Sets Kling-Net protocol
Art-Net
IP Mode
Manual
Sets product to use a manually set IP address
DHCP
Sets product to use dynamic IP addressing
Static
Sets product to use its internal IP address
Net
000–127
Sets the net address of the product
Subnet
00–15
Sets the subnet of the product
Universe
Sets the universe of the product
