Control Panel
Description
Button
Function
<MENU>
Scrolls through the main menu options or exits the current menu option.
<ENTER>
Enters into the highlighted menu option or sets the currently selected value.
<UP>
Navigates up through a list of menu options or values.
<DOWN>
Navigates down through a list of menu options or values.
Home Screen
The home screen on the control panel display shows the current operating state
as follows:
• <Master> if the Nexus™ 4x4 is in Standalone or Master mode
• <Slave> if the Nexus™ 4x4 is in Art-Net™, Kling-Net, or DMX mode
Exiting Auto
Show
And
Static Modes
Auto Show and Static modes are not exited automatically when another
mode is selected. To exit Auto Show or Static mode, do the following:
1. Go to the Master/Slave main level.
2. Select Slave.
3. Press <ENTER>.
4. Press <MENU> for 10 seconds.
Setting changes are not activated until the control panel display
returns to the home screen. To return the control panel display to the
home screen press and hold <MENU> for 10 secs.
Menu Map
Main Level
Programming Levels
Description
Auto Show
Auto 1–12
Show Speed
000–100
Selects an auto program and its speed
Fade
Selects color fade and its speed
Static
Fixture Color
R
Selects a preset color
G
B
GB
RB
RG
RGB
Manual Color
R
G
B
000–255
Sets color levels for manual color mixing
Dimmer Mode
Off
Sets dimming curve
Dimmer 1–3
Back Lite
On
Sets control panel backlight time
10S
20S
30S
