INSTALLATION DE BASE
2
b
INSTALLATION
Desserrer A et retirer B
Installer "C" sous le fond en
aluminium et fixer "B-1".
Photo après
l'installation
1
A
B
B-1
B-1
C
2
FR
Intel LGA 775/115x/1366/1200/1700
AMD FM1/FM2/AM2/AM2(+)/AM3(+)/AM4/AM5
A
