USER’S MANUAL

Fuse

Input

Output

INSTALLATION AND OPERATION

Installation for Standard UPS

1. Shutdowntheload(forexamplePC),pulloutpowergird.

2.PutUPSontheproperposition(followingthemanual).

3.Connectload(forexamplePC)totheUPS.

4.PuttheplugtotheACpowersocket(makesureGNDis

connectedwell).

5.ConnecttoAC:pressthepanelswitchturningontheUPS,

thegreenLEDandyellowLEDlight,thenyoucanturnonyour

computeretc.

6.Batterymode:pressthepanelswitchturningontheUPS,the

redLEDlights,thenyoucanturnonyourcomputeretc.

7.NormallyturningUPS:pressthepanelswitchturningonthe

UPS.

8.NormallyturningoUPS:pressthepanelswitchturningo

theUPS.

NGS FORTRESS User Manual

Questions and Answers:
