4
Instruction Manual
US
HE.13575_A © 06/2010
PC-280
4
Instruction Manual
4. Troubleshooting
a.) Constant fl ashing/indicating of the LED light (page I,
pic 1.1) or the occurence of an acoustical warning sig-
nal.
see table 1. If the failure cannot be resolved, return the
tool to the nearest service center (ASC).
b.) The tool loses oil.
Return the tool to the nearest ASC. Do not open it and
damage the seal of the tool.
c.) The red LED fl ashes 3x and simultaneously 3 acou-
stic warning signals occure (see table 1).
Serious fault! If this fault occures repeatedly return the
unit to an Authorized Service Center (ASC). Do not
open it and damage the seal of the tool.
In case of a one time occurence, the fi tting has to be
dismantled or pressed a second time.
5. Technical Data
Weight
(incl. battery):
9.5 lbs
Thrust force (linear): 32 kN min.
Driving motor: direct-current permanent fi eld
Battery voltage: 18 V DC
Battery capacity: 3 Ah (PC-7L)
Charging time: 22 min. (PC-7L)
Pressing time: 4s to 7s (depending on the
nominal width)
Pressing
performance:
approx. 300 compressions/
battery with 3/4“
Hydraulic oil: Rivolta S.B.H. 11
Environmental tem-
perature:
-4°F to +104°F
Sound level: 70 dB (A) in 1m distance
Vibrations: < 2.5 m/s²
Dimensions: See page II, pic. 2
