2 close tones + 1 tone Signals an invalid combination
3 tones Signals the correct execution of the programming
procedure
1 tone with regular frequency Signals that the keyboard is blocked
Series of tones Signals that an error has been made;
programming failed
• During normal functioning or during the various programming phases, the key-
board emits a luminous signal; refer to Table 5:
TABLE 5
Device lighting Description
Fixed RED on Gate closed and automation released
Fixed RED on Gate in closing phase
Fixed RED on Gate not closed or open and automation released
Fixed GREEN on Gate in opening phase
Fixed GREEN on Gate not closed or open and automation blocked
Fixed GREEN on Gate open and automation blocked
Fixed GREEN on Gate closed and automation blocked
RED (3 flashes and pause) Keyboard not synchronised onto the bluebus
RED (3 flashes and pause) Keyboard without “jumper"
6.1 - Procedure for changing the type of command
associated to a combination
With this function it is possible to change the command assigned to the “” and
“” keys. It is possible to select which command to couple to the pre-selected key,
among those available in Table 6. Some commands could be different with respect
to the control unit to which the keyboard is connected (see respective instruction
manual). During the execution of the procedure, press the “P” key (fig. 3) to select a
new command (every time the key is pressed during the procedure it allows to
select the successive command present in Table 6). Respect the maximum time of
10 seconds between one entry and the next, otherwise the previous command is
reconfirmed and the procedure must be repeated.
TABLE 6
N° of flashes Command
1 flash + pause Step-by-Step (“” factory-setting)
2 flashes + pause Opening
• When the electric power input is applied to the control unit, the keyboard
LEDs flash in red to indicate the type of memory present plus 5 flashes if the
memory is empty; refer to Table 3:
TABLE 3
N° of flashes Description
1 BM60
2 BM250
3 BM1000
4 Indicates that the memory has invalid codes
5 Error during reading of the memory
5 (lenses) Empty memory
• During the programming phase the keyboard emits acoustic tones to signal
regular functioning or errors; refer to Table 4:
TABLE 4
Acoustic tone Description
1 tone Indicates a key is being pressed
8 – English
EN
FURTHER INFORMATION
6
After having performed the memorisation and learning of MOTB, it is necessary
to check the correct functioning:
a) check that everything envisioned in chapter 1 - Recommendations and gen-
eral precautions have been respected;
b) use the keyboard to enter a valid combination and press the “” or “”: key:
at the same time observe whether the automation performs the control sent
and if the keyboard lighting corresponds to the control sent (see Table 5). If
this is not the case, see chapter 7 - "What to do if....troubleshooting”.
c) check that the other combinations have also been memorised correctly.
INSPECTION
5
