Nice PS 524 User Manual

English – 3
ENGLISH
WORKING IN SAFETY!
• CAUTION! – For personal safety it is important to observe these instruc-
tions.
• CAUTION! – Important safety instructions: Keep these instructions in a
safe place.
• CAUTION! – All product installation, connection, testing, commission-
ing and maintenance operations must be performed exclusively by a
qualied and skilled technician.
Caution! – Observe the following warnings:
•Neverapplymodicationstoanypartofthedevice.Operationsotherthanas
speciedcanonlycausemalfunctions.Themanufacturerdeclinesallliabilityfor
damagecausedbymakeshiftmodicationstotheproduct.
•Donotimmersethechargeunitorbatteriesinwaterorotheruids.Ifliquids
penetratethedeviceinterior,disconnectitimmediatelyfromtheautomationand
contacttheNiceAssistanceService;useofthedeviceintheseconditionscon-
stitutesahazard.
•Neverplacethedevicenearsourcesofheatandneverexposetonakedames.
Thismaydamagetheunitandcausemalfunctions.
• Disconnect the system from the power mains before installing and con-
necting the batteries and charge unit.
•Beforeinstallingthechargeunitandbatteries,checktheconditionofthepro-
ductcomponentsandsuitabilityoftheselectedmodelwithreferencetothe
“producttechnicalspecications”.
•Ifinanydoubtregardinginstallation,donotproceedandcontacttheNiceTech-
nicalAssistanceforclarications.
•Theproductpackagingmaterialmustbedisposedofinfullobservanceofcur-
rentlocallegislationgoverningwastedisposal.
•Intheeventofperiodsofdisuse,disconnectitfromtheautomationandstorein
adrylocationtoavoidtheriskofleaksofharmfulsubstances.
GENERAL SAFETY WARNINGS
AND PRECAUTIONS
1
Thisproductisa chargeunit usedasaninterfaceforhookingupVRLA12V7A/h
(Niceart.B12-B)rechargeablesealedleadacidbatteriesinautomationsforgates
andgaragedoorsusingNicecontrolunits.CAUTION! – Any use other than as
described herein is to be considered improper and is strictly prohibited!
Thesystemsuppliesemergencypowertoanautomationintheeventofasudden
powerfailure.
Whenthebatteryischargeditcanguaranteeautomationautonomyofapprox.
10manoeuvres.Othercharacteristicsareprovidedinthechapter“ProductTech-
nicalSpecications”.
PRODUCT DESCRIPTION AND
INTENDED USE
2
Installandconnectthesystemwithreferencetotheinstructionmanualofthe
automationtowhichitistobeconnected.
ToconnectthePS524chargeunittothetwobatteries,referto g. 1:usethecable
withtheFastonconnectors(makesurethecablecoloursand+/-polarity ofthe
connectionsmatchasindicated(red +;black -).
ToconnectthePS524chargecardtothecontrolunit,refertog. 2:usethepro-
videdcable. Caution! - The cable is not polarised and therefore can be con-
nected to the connectors on either side.
INSTALLATION AND CONNECTION
3
Thefollowingchecksmustbeperformedimmediatelyafterconnectingthebuffer
batterytothecontrolunit.
1 on the charge unit: ensurethatled“L2”(g. 3)islit;thisindicatesthatthe
batteryissupplyingpowertothesystem.
On the Control unit: ensurethattheledsindicatecorrectoperationofthe
controlunit.
 Iftheresultisnotpositivethebatteriesareprobablycompletelydrained.At
thispoint,withtheautomationpoweredbythemains,performtheoperation
describedinpoint“2”.Important–Waitafewhoursbeforerepeatingthe
operationcheck.
2 Connecttheautomationtotheelectricalmainsandensurethatchargeunitled
“L1”(g. 3)islit;thisindicatesthatthebatteryisrechargingcorrectly.
3 RunacompleteOpeningorClosingmanoeuvreoftheautomationtoensure
correctoperationoftheentiresystemwhenpoweredbythemains.
4 Disconnecttheautomationfromthemainsandcheckthatchargeunitled“L2”
(g. 3)islit;thenrunatleastonecompleteOpeningandClosingmanoeuvre
oftheautomationtocheckthattheentiresystemoperatescorrectlywhen
poweredbythebatteriesalone.
5 Attheendoftheabovechecks,reconnecttheautomationtothepowermains.
TESTING AND COMMISSIONING
4
DISPOSAL OF THE PRODUCT
This product constitutes an integral part of the automation system,
therefore it must be disposed of along with it.
Asininstallation,alsoattheendofproductlifetime,thedisassemblyandscrap-
pingoperationsmustbeperformedbyqualiedpersonnel.
Thisproductismadeupofdifferenttypesofmaterial,someofwhichcanbe
recycledwhileothersmustbedisposedof.Seekinformationontherecyclingand
disposalsystemsenvisagedbythelocalregulationsinyourareaforthisproduct
category.
Caution!–somepartsoftheproductmaycontainpollutantorhazardoussub-
stanceswhich,ifdisposedofintotheenvironment,maycauseseriousdamageto
theenvironmentorphysicalhealth.
Asindicatedbythesymbolontheleft,disposalofthisproduct
indomesticwasteisstrictlyprohibited.Separatethewasteinto
categoriesfordisposal,accordingtothemethodsenvisaged
bycurrentlegislationinyourarea,orreturntheproducttothe
retailerwhenpurchasinganewversion.
Caution!–Locallegislationmayenvisageseriousnesinthe
eventofabusivedisposalofthisproduct.
PRODUCT MAINTENANCE
Thebufferbatterydoesnotrequiremaintenance,butintheeventofprolonged
disuse,disconnectfromtheautomationandstoreinadrylocation.
Replacementofbatteriesisrequiredwhenautonomyissignicantlyreduceddue
toage.Thisoperationmayonlybeperformedbyqualiedtechnicalpersonnel;
contactNICEforassistance.
EN

Nice PS 524 Specifications

General

Brand	Nice
Model	PS 524
Category	Battery Charger
Language	English
