Nicotra RZR Series User Manual

Mounting Instructions EN
MA-CFB_BEARING 4.4 – 02/2020 6
Self-aligning bearing
with clamping sleeve and cast housing
RZR 13-0400/-1600 (IWN)
RER 13-0200/-1600 (IWN)
RER 17-0200/-1000 (IWN)
(Page 2 of 3)
Table 2 (only for RZR)
Fan- Size
Bearing Type
Bearing Type
Bearing
clearance
C3 before
mounting
[µm]
Radial internal clearance in mm
Bearing housing type
Tightening torque Connecting bolts Cast casing
SKF-
bearing
SNR-
bearing
FAG bearing
Step 1:
Tightening torque
Step 2:
Angle
min. max.
Tightenin
g angle 
Tightenin
g angle 
FAG
tool
Torque
tool
+ Tightening
angle 
RZR 0400
RZR 0450
RZR 0500
2307 K/C3
+ H 2307
Self-aligning bearing
29 46
SKF: SNL 508-607 TG
SNR SNC 508-607
FAG SNV 080-L
=> 50Nm / M10
=> 65Nm / M12
=> 36Nm / M10
70° 80° 35 Nm 38 Nm + 66°
RZR 0560
RZR 0630
2309 K/C3
+ H 2309
33 52
SKF SNL 511-609 TG
SNR SNC 511-609
FAG SNV 100-L
=> 80Nm / M12
=>150Nm / M16
=> 61Nm / M12
70° 80° 58 Nm 61 Nm + 72°
RZR 0710
RZR 0800
2311 K/C3
+ H 2311
41 61
SKF SNL 513-611 TG
SNR SNC 513-611
FAG SNV 120-L
=> 80Nm / M12
=>150Nm / M16
=> 61Nm / M12
75° 100° 93 Nm 100 Nm + 66°
RZR 0900
RZR 1000
2313 K/C3
+ H 2313
50 75
SKF SNL 516-613 TG
SNR SNC 516-613
FAG SNV 140-L
=> 80Nm / M12
=>290Nm / M20
=> 61Nm / M12
80° 100° 97 Nm 107 Nm + 80°
RZR 1120
22216 EK/C3
+H316
Self-aligning bearing
95 120
0,03
to
0,04
SKF SNL 516-613 TG
SNR SNC 516-613
FAG SNV 140-L
=> 80Nm / M12
=>290Nm / M20
=> 61Nm / M12
130°
Control
value
:
0,04
Tighten the sleeve nut according to the
column “Radial internal clearance”;
play 0,045-0,08
Control value for the lowest radial play:
0,04mm
RZR 1250
22218 EK/C3
+H318
110 140
0,04
to
0,05
SKF SNL 518-615 TG
SNR SNC 518-615
FAG SNV 160-L
=>150Nm / M16
=>290Nm / M20
=>150Nm / M16
150°
Control
value
:
0
,
05
Tighten the sleeve nut according to the
column “Radial internal clearance”; play 0,05
… 0,095
Control value for the lowest radial play:
0.05mm
RZR 1400
RZR 1600
22220 EK/C3
+H320
110 140
0,045
to
0,06
SKF SNL 520-617 TG
SNR SNC 520-617
FAG SNV 180-L
=>200Nm / M20
=>500Nm / M24
=>301Nm / M20
150°
Control
value
:
0
,
05
When mounting new bearing components, observe the enclosed instruction manual and, where applicable, the
instructions and values provided by the respective manufacturer!
CAUTION!
As the types of the FAG and the “standard”
torque wrench differ, the correct torque values
as mentioned in Step 1 of the bearing fitting
must be used!
It is not permitted to interchange the processes.
For the FAG tool the centre of the locknut and
the torque of the release mechanism are not
identical.
This results in different leverages, and
therefore, settings, for both torque wrenches
q q
Locknut Fulcrum / inflexion point
fulcrum of FAG torque wrench
