iControl Messages
Manual # 42-02-7223 C1 6-35
6
iControl DC
Emergency Brake UIM Reset Button Stuck, EM BK UIM RESET STUCK
Description: The reset button on the Rope Gripper board (ICE-RG) or Emergency Brake board (ICE-EB) has
been activated for more than 15 seconds.
Car Reaction: The car is not allowed to move. If in motion, the car is allowed to finish the run.
Troubleshooting: Check the reset button on the ICE-RG or ICE-EB board.
Emergency Dispatch On, Emergency Dispatch, EMERGENCY DISPATCH
Description: The car is automatically servicing the building in a pre-defined pattern. This operation is
invoked when a failure of the hall calls bus or group communication is detected. This operation may also be
activated using a key switch input.
Car Reaction: The car automatically moves to every floor in the building in a predefined pattern and cycles
its doors.
Tro ubleshooting:
1. Check group/car communications.
2. Check the hall call bus drivers.
3. Check the Emergency Dispatch input.
Emergency Dispatch Off (see Emergency Dispatch On)
Emergency Medical Service Bypassed
Description: EMS is active but has been bypassed by another mode of operation.
Car Reaction: EMS service is bypassed and the car operates under the new mode of operation.
Tro ubleshooting:
1. Check the current mode of operation and the EMS user settings.
Emergency Medical Service Deactivated
Description: EMS has been deactivated.
Car Reaction: Car is returned to prevailing mode of operation.
Tro ubleshooting: NA
Emergency Medical Service In-Car Activated (Switch ‘n’), EMS In-car (Switch ‘n’) (n = 1 or 2)
Description: EMS In-Car service activated by in-car EMS switch. Also referred to as EMS Phase II operation.
Car Reaction: Car remains out of hall call service. Car calls are enabled. After answering a car call, doors will
open automatically but close with constant pressure on Door Close Button only.
Tro ubleshooting:
1. EMS In-Car terminated by taking car to EMS recall floor by car call and deactivating in-car EMS switch or
by removing in-car EMS switch from pre-programmed IO configuration.
2. Related inputs:
EMSCarSwitch0: Normally low
EMSCarSwitch1: Normally low
Emergency Medical Service Recall Activated (Switch ‘n’), EMS Recall (Switch ‘n’) (n = 1 or 2)
Description: EMS recall activated via one of the EMS recall key-switches located next to the designated EMS
elevator. This is also referred to as the EMS Phase I operation.
Car Reaction: Momentary activation of EMS recall switch will initiate recall to user-defined EMS Recall floor.
Car removes itself from car and hall call service. Once at EMS recall floor, door operation is in accordance to
user-defined door operation under EMS recall. Car will remain on EMS Phase I as long as hall switch is acti-
vated. Once hall switch is deactivated, car will return to normal operation upon expiration of user-defined
timer if in-car switch has not been activated.
Tro ubleshooting:
1. Verify no hall EMS recall switch is activated.
2. EMS Recall operation can also be terminated by removing in-car EMS switch from pre-programmed IO
configuration.
3. Related inputs:
EMSHallSwitch0: Normally low
EMSHallSwitch1: Normally low
Table 6.3 iControl Messages
iControl Messages
