Troubleshooting
6-50 Manual # 42-02-7223 C1
Insufficient Motor Field Forcing Feedback Fault, INSFCNT MF FORCNG FLT
Description: Motor field voltage is inadequate. DC motors only.
Tro ubleshooting:
1. Verify motor field voltage parameters.
2. The motor field may be improperly calibrated. Check settings (iView Motor Configuration screen).
3. Recalibrate motor field if necessary.
Invalid Configuration BALRQ, INVALID CNFG BALRQ
Description: Bottom Access Landing Rear Qualifier. The safety system has detected the improper use of
BALRQ option on the iView safety configuration screen.
Car Reaction: Safety OK status remains off.
Tro ubleshooting:
1. Check that the Safety Configuration, Bottom Access Landing Rear option is properly set.
Invalid Configuration Input, INVALID CNFG INPUT
Description: An invalid input was discovered when cross checking safety inputs against safety configuration.
Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped.
Tro ubleshooting:
1. Check car setup/wiring against Safety Screen configuration.
2. Press Fault Reset to clear.
3. Re-learn Safety Configuration.
Invalid Configuration Input Off (See: Invalid Configuration Input)
Invalid Configuration Input CTEX, INVLD CNFG INPUT CTEX
Description: Cartop Emergency Exit. The safety system detected an input/safety setting difference when
cross checking inputs against configuration.
Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped.
Tro ubleshooting:
1. Verify car setup/wiring matches the Safety screen setting for the option.
2. Press Fault Reset to clear.
3. Re-learn the Safety Configuration.
Invalid Configuration Input DCAB, INVLD CNFG INPUT DCAB
Description: Door Close Access Bottom. The safety system detected an input/safety setting difference when
cross checking inputs against configuration.
Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped.
Tro ubleshooting:
1. Verify car setup/wiring matches the Safety screen setting for the option.
2. Press Fault Reset to clear.
3. Re-learn the Safety Configuration.
Invalid Configuration Input DCAT, INVLD CNFG INPUT DCAT
Description: Door Close Access Top. The safety system detected an input/safety setting difference when
cross checking inputs against configuration.
Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped.
Tro ubleshooting:
1. Verify car setup/wiring matches the Safety screen setting for the option.
2. Press Fault Reset to clear.
3. Re-learn the Safety Configuration.
Table 6.3 iControl Messages
iControl Messages
