iControl Messages
Manual # 42-02-7223 C1 6-55
6
iControl DC
IO Map Compare Fault, IO MAP COMPARE FAULT
Description: Safety A IO Map did not match Safety B IO Map.
Car Reaction: If running, car makes an emergency stop. Car is not allowed to run.
Tro ubleshooting:
1. Before the fault has been cleared, you can access additional information about this fault by clicking the
Generate IO Map Fault Report button on the iView > Controller > View > Diagnostics > Data Trap tab.
2. Press the Fault Reset button to clear the fault.
3. If problem persists it is an indication that the iBox may need to be replaced. Consult MCE Technical Sup-
port for instructions.
IO Map Compare Fault Off (See: IO Map Compare Fault)
IO Map Compare Long Term Fault, IO MAP COMPARE LT FLT
Description: Safety A long term products did not match Safety B long term products for 1.2 seconds.
Car Reaction: If running, car makes an emergency stop. Car is not allowed to run.
Tro ubleshooting:
1. Press the Fault Reset button to clear the fault.
2. If problem persists it is an indication that the iBox may need to be replaced. Consult MCE Technical Sup-
port for instructions.
IO Map Toggle Compare Fault, IO MAP TOGLE COMP FLT
Description: The failure of a safety input was detected during the “input toggle test” (performed at the end of
each run). This test verifies the proper operation of safety system inputs that normally remain unchanged
during the course of elevator operation.
Car Reaction: Emergency stop: Motor contactor and brake contactor immediately dropped.
Tro ubleshooting:
1. Before the fault has been cleared, you can access additional information about this fault by clicking the
Generate IO Map Fault Report button on the iView > Controller > View > Diagnostics > Data Trap tab.
2. Press the Fault Reset button to clear the fault.
3. If problem persists it is an indication that the iBox may need to be replaced. Consult MCE Technical Sup-
port for instructions.
IO Map Toggle Compare Fault Off (See: IO Map Toggle Compare Fault)
iView Logged Off. Passenger operation. A previously active iView connection to the controller has logged
off.
iView Logged On. Passenger operation. An iView user has logged on to the controller.
iView Lost Connection. An iView connection has been dropped.
iView Timed Out. An iView connection was inactive for a period of time beyond the idle time out and has
been disconnected.
Jail Master Mode
Description: The car has been placed in Jail Master Mode via the Jail Master Mode Input or via the Jail Oper-
ation PC application.
Car Reaction: The car operates as configured via the Jail > Master mode parameters.
Jail Secure Mode
Description: Car placed in Jail Secure Mode via Jail Secure Mode Input or Jail Operation PC application.
Car Reaction: The car operates as configured via the Jail > Secure mode parameters.
KTR Machine Brake Pressure Switch Fault (Custom Event)
Description: A pressure switch fault was detected on the KTR brake controller (machine brake).
Car Reaction: Car performs an emergency stop.
Troubleshooting: Refer to the KTR brake controller manual for troubleshooting information.
KTR Machine Brake Oil Level Fault (Custom Event)
Description: A low oil level was detected on the KTR brake controller (machine brake).
Car Reaction: Car stops at next call destination.
Table 6.3 iControl Messages
iControl Messages
