Rear Photo Eye 2 Bypassed, REAR PHOTO EYE2 BYP
Description: The auxiliary rear photo-eye device (required for Peele doors for PHE integrity tests) has been
continuously activated for a user-defined time and is now bypassed in accordance to the user-defined set-
tings (Configuration > Car Operation > Doors > Door Device > Photo Eye).
Car Reaction: The auxiliary rear photo eye device is rendered inoperative.
Tro ubleshooting:
1. To restore the operation of the photo eye device, check the corresponding input.
2. The operation of the photo eye device can also be restored by changing the Photo Eye Bypass option to
NO on iView.
3. Related Inputs: PHE2 Rear - Normally low
Rear Photo Eye Failure, REAR PHOTO EYE FAIL
Description: This event is logged when the photo eye is continuously activated for a predetermined time (4
seconds) while the rear doors are fully closed.
Car Reaction: The rear photo eye is rendered inoperative.
Tro ubleshooting:
1. Check for abnormal blockage or failure of the rear optical device.
2. Related inputs:
RearPhotoEye: Normally low.
Rear Photo Eye 2 Failure, REAR PHOTO EYE2 FAIL
Description: The auxiliary rear photo eye device (required for Peele doors for PHE integrity tests) was contin-
uously activated for a predetermined time (four seconds) while the rear doors are fully closed.
Car Reaction: The auxiliary rear photo eye is rendered inoperative.
Tro ubleshooting:
1. Check for abnormal blockage or failure of the auxiliary rear optical device.
2. Related Inputs: PHE2 Rear - Normally low
Rear Photo Eye Test Fail, REAR PHOTO TEST FAIL
Description: The rear photo eye devices integrity test (required under section 2.13.3.4.9 of the A17.1a-
2008/CSA B44a-08 elevator safety code) has failed. Indicating that one or both the main and auxiliary rear
photo eye devices are not functioning properly and unable to detect an object.
Car Reaction: Car remains in service. Rear doors are prevented from closing. The rear photo eye devices
integrity test is repeated until it is determined that both the main and auxiliary rear photo eye devices are
able to detect an object.
Tro ubleshooting:
1. Check that both the main auxiliary rear photo eye devices are functioning properly and able to detect an
object.
2. Related Inputs: Rear photo eye and PHE2 Rear – Both Normally low
Rear Safe Edge Bypassed, REAR SAFE EDGE BYP
Description: The rear door safe edge has been continuously activated for a user-defined time and is now
bypassed according to the user-defined setting. (iView Controller > Configuration > Car Operation > Doors).
Car Reaction: The rear safe edge is rendered inoperative.
Tro ubleshooting:
1. Check the state of the rear safe edge input.
2. Related input - SafeEdgeRear: Normally low.
Rear Safe Edge Failure, REAR SAFE EDGE FAIL
Description: This event is logged when the rear door safe edge is continuously activated for a predetermined
time (4 seconds) while the rear doors are fully closed.
Car Reaction: The rear door safe edge is rendered inoperative.
Tro ubleshooting:
1. Check for abnormal blockage or failure of the rear door mechanical reopening device.
2. Related inputs:
RearSafeEdge: Normally low.
