Reference
9-2 Manual # 42-02-7223 C1
iControl DC Specifications
Table 9.1 iControl DC Specifications
Parameter Specification
Car Speed Up to 1800 fpm (9.14 m/s)
Jerk
15 ft/sec
3
(7.62 m/sec
3
) maximum
8 ft/sec
3
(2.44 m/sec
3
) nominal
1 ft/sec
3
(0.305 m/sec
3
) minimum
Acceleration
10 ft/sec
2
(3.04 m/sec
2
) maximum
4 ft/sec
2
(1.52 m/sec
2
) nominal
1 ft/sec
2
(0.31 m/sec
2
) minimum
Number of Stops Up to 96 (60 floors for Simplex)
Number of Cars in Group Up to 15
Floor Leveling Accuracy +/- 0.25 inches (6.35mm) guaranteed
+/- 0.125 inches (3.18mm) typical
Minimum Floor to Floor Time 4.8 seconds for 12-foot (3.66m) floor heights if rotating equipment is
capable of delivering the necessary torque.
Environmental Limits 32 to 104 degrees F (0—40 degrees C) ambient
12,000 ft (3,658m) altitude
95% relative humidity (non-condensing)
