7.8 PVR FUNCTION
Base on USB PVR function you could record the preference program and playback.
Instant recording, EPG recording and timer recording were available.
8.8.1 Instant recording
Press REC. key to start instant recording during watch TV and the recording symbol
would be display on the left top of the screen. Press INFO. key to get further more
information of instant recording. Press STOP key to stop instant recording.
12
11
10
9
8
Player
Music
Movie
Supported file
JPEG, BMP, PNG
*.wma, *.mp3, *.m4a
*.avi, *.mpg, *.dat, *.ts etc
2)Photo Configure: Press OK key to setup pictures
playing.
3)Movie Configure: Press OK key to setup movie
playing.
7.7.1 Multimedia
Insert U disk, select Multimedia item, press leftward
/rightward key to select the followings(Music, Photo,
Movie, PVR)to play, then press OK key to play from
selected file.
Multimedia player feature also has been integrated
on the receiver. Press PVR key to display multimedia
player window. You could show your preference photo,
playing music and movie on multimedia player. Known supported file were
illustration below. NTFS, FAT32 file system could be supported at the moment.
4)PVR Configure: Press OK key to setup program record.
Base information bar Further more information bar.
7.9 INFO. KEY
Press "INFO" key to displaying base information bar during watching TV programs.
Press "INFO" key twice to displaying further more program information during
watching TV.
7.10 SUBTITLE KEY
The programs might have multilingual subtitle
information. All available subtitle languages
would display on the subtitle information window
while you press SUBTITLE key. The screenshot
is illustrated below. Follow the help information
on the subtitle windows to select preference
subtitle.
7.11 UPDATE THE RECEIVER BY USB INTERFACE
NOTE:
1)Plug the USB drive that with the update file to the USB interface of the receiver.
2)G
o to main menu and press to start upgrade process. While the upgrade progress
showing 100% and update finish, remove the USB flash drive and power on the
receiver again.
3)Please set the receiver to the factory settings after reboot the receiver.
Please do not remove the USB drive from the receiver and power off the
receiver during upgrading process. Otherwise the receiver may not work properly.
Check whether the antenna is adjusted properly;
The signal strength is too weak.
Check whether the volume is minimized; Check
whether the headset is connected; The signal quality
is poor.
Check whether the antenna is located well;
Check the parameter of image or region is set
correctly; if not, please set or search again.
No signal
No sound
Mosaic images
Signal search failure
Check whether the country and region is set right;
Maybe the signal intensity is too poor.
Too-dark images
Check whether the brightness and contrast of your
display is adjusted well; if not, readjust it.
May the signal intensity in this region is too weak.
Please try a vehicle digital TV antenna.
Mosaic images or slack images
/sound occur when the car is
moving
9. Troubleshooting
The following phenomenon does not indicate failures. Before you contact us for
repair, please check your device according to the approaches below.
The AC adapter does not connect to the vehicle
adapter properly; Non-permissible power is applied;
The power is off.
Causes
No picture or sound
Problems
10. Specifications
Causes
Problems
To prevent injury, this apparatus must be securely attached to the floor/wall in
accordance with the installation instructions.
The mains plug is used as the disconnect device, the disconnect device shall
remain readily operable, and it shall be disconnected from the mains completely.
The plug is used as disconnect device form the mains supply, the plug shall
remain readily operable.
The apparatus should not be exposed to dripping or splashing and that no
objects filled with liquids, such as vases, shall be placed on the apparatus.
No naked flame sources, such as lighted candles, should be placed on the
apparatus.
Power supply:
Connector:
Supported power:
Dimension:
Weight:
Resolution:
Working temperature:
Storage temperature:
DC 12V 10 W
Input jack for external antenna; stereo headset jack;
audio/video (AV) input jack;
DVB-T(AV) output jack and input jack for external source
Two options: 1. Alternating current power supply - AC adapter
2. Vehicle battery (12 V)-vehicle adapter
about
480 RGB 234
-5 - 40
-40 - 60
Warning
Warning
This manual is for your reference only. The information in the Manual is subject to
change without prior notice. The company reserves the right to explain for any
unknowns, errors or omissions.
No elements are recoverable inside your device. Do not attempt to open it to
improve your TV set. The high-tension supply inside may cause dangers. The
maintenance and adjustment of your TV set must be operated by professionals.
232 135 38 (mm)
516g
after some items in this manual means it is available with this function.
7.7.2 Photo configure
The number of parameters when set the picture in slide show mode:
1) Slide Time:the play time of slide show
2) Slide Mode: the style of slide show
3) Aspect Ratio: you can set up Keep or Discard
7.7.3 Movie Configure
1) Aspect Ratio:You can set up Keep or Discard.
2) Subtitle Specific: You can set up NORMAL, BIG or SMALL
3) Subtitle Background : You can set up Transparent, Gray, Yellow green, white
4) Subtitle Font color: You can set up Red, Blue, Green, white,Black
7.7.4 PVR Configure
1) Record Device: Check the stored information
2) Format: Clear information
DTV system:
Input frequency:
Modulate:
Decode standard:
Audio decode standard:
VHF 177.5 MHz-226.5 M z UHF 474 MHz - 858 z
QPSK/16-QAM/64-QAM
MPEG1, HD MPEG2, SD MPEG2, MPEG4
(H.264/AVC: HP@L4.1, MP@L4.1, VC-1: AP@L3, L2)
MPEG1 LAYER 1, II MUSICAL, MPEG-4 HE-AAC
HMH
General characteristic
Display:
Screen size:
Speaker:
Colour TFT-LCD
7 inches
two 40mm round loudspeaker
