On the Lens
The lenses you use with your Nikon
D40/D40x each have their own set of con-
trols. Figure 1.9 shows two lenses: the very
basic 18-55mm f/3.5-5.6G ED II AF-S DX
Zoom-Nikkor and the more upscale 18-
200mm f/3.5-5.6G ED-IF AF-S VR DX Zoom-
Nikkor vibration reduction lens. Not all
lenses have all the possible controls.
Chapter 1 ✦ Exploring the Nikon D40/D40x 21
Zoom ring
Focus ring
Filter thread
Lens hood bayonet mount
Zoom ring
Focal length scale
Filter thread
Focal length scale
Automatic/Manual focus switch
Mounting
index
Automatic manual override/
Manual focus switch
Focus ring
Distance scale
Vibration Reduction switches
1.9 The controls found on the 18-55mm kit lens (left) and 18-200mm vibration reduction
lens (right).
