Nikon D5200 Reference Manual

233
ISO sensitivity
(Recommended
Exposure Index)
ISO 100 – 6400 in steps of
1
/3 EV. Can also be set to approx. 0.3, 0.7, 1, or
2 EV (ISO 25600 equivalent) above ISO 6400; auto ISO sensitivity control
available
Active D-Lighting Auto, extra high, high, normal, low, off
Focus
Autofocus Nikon Multi-CAM 4800DX autofocus sensor module with TTL phase
detection, 39 focus points (including 9 cross-type sensor), and AF-assist
illuminator (range approx. 0.5–3 m/1 ft 8 in.–9 ft 10 in.)
Detection range –1 – +19 EV (ISO 100, 20 °C/68 °F)
Lens servo • Autofocus (AF): Single-servo AF (AF-S); continuous-servo AF (AF-C); auto
AF-S/AF-C selection (AF-A); predictive focus tracking activated
automatically according to subject status
• Manual focus (MF): Electronic rangefinder can be used
Focus point Can be selected from 39 or 11 focus points
AF-area mode Single-point AF, 9-, 21-, or 39- point dynamic-area AF, 3D-tracking, auto-
area AF
Focus lock Focus can be locked by pressing shutter-release button halfway (single-
servo AF) or by pressing A (L) button
Flash
Built-in flash i, k, p, n, o, s, w, g: Auto flash with auto pop-up
P, S, A, M, 0: Manual pop-up with button release
Guide Number Approx. 12/39, 13/43 with manual flash (m/ft, ISO 100, 20 °C/68 °F)
Flash control TTL: i-TTL flash control using 2016-pixel RGB sensor is available with
built-in flash and SB-910, SB-900, SB-800, SB-700, SB-600, or SB-400; i-TTL
balanced fill-flash for digital SLR is used with matrix and center-weighted
metering, standard i-TTL flash for digital SLR with spot metering
Flash mode Auto, auto with red-eye reduction, auto slow sync, auto slow sync with
red-eye reduction, fill-flash, red-eye reduction, slow sync, slow sync with
red-eye reduction, rear-curtain with slow sync, rear-curtain sync, off
Flash compensation –3 – +1 EV in increments of
1
/3 or
1
/2 EV
Flash-ready indicator Lights when built-in flash or optional flash unit is fully charged; flashes
after flash is fired at full output
Accessory shoe ISO 518 hot-shoe with sync and data contacts and safety lock
Nikon Creative Lighting
System (CLS)
Advanced Wireless Lighting supported with SB-910, SB-900, SB-800, or
SB-700 as a master flash or SU-800 as commander; Flash Color
Information Communication supported with all CLS-compatible flash
units
Sync terminal AS-15 sync terminal adapter (available separately)
White balance
White balance Auto, incandescent, fluorescent (7 types), direct sunlight, flash, cloudy,
shade, preset manual, all except preset manual with fine-tuning.
Exposure

Nikon D5200 Specifications

General

Megapixel	24.1 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	24.71 MP
Image sensor size	- \
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	6000 x 4000
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Continuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 6400, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed	1/200 s
Power source type	Battery
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	59.94 fps
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio formats supported	PCM
Internal memory	0 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	921000 pixels
Magnification	0.78 x
Viewfinder type	Optical
USB version	2.0
Product color	Bronze
Scene modes	Beach, Candlelight, Children, Close-up (macro), Dawn, Dusk, Night landscape, Night portrait, Party (indoor), Portrait, Self-portrait, Snow, Sports, Sunrise, Sunset, Landscape (scenery)
Photo effects	Neutral, Vivid
White balance	Auto, Cloudy, Fluorescent, Incandescent, Manual, Shade, Sunny
Shooting modes	Aperture priority, Auto, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL14
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Cables included	AV, USB

Weight and Dimensions

Depth	78 mm
Width	129 mm
Height	98 mm
Weight	555 g
