Nikon D5200 Reference Manual

17
9 Focus the viewfinder.
After removing the lens cap, rotate the diopter
adjustment control until the AF area brackets are
in sharp focus.
When operating the control with
your eye to the viewfinder, be careful not to put
your fingers or fingernails in your eye.
A Adjusting Viewfinder Focus
If you are unable to focus the viewfinder as described above, select single-servo autofocus
(AF-S; 0 33), single-point AF (c; 0 36), and the center focus point, and then frame a high-
contrast subject in the center focus point and press the shutter-release button halfway to
focus the camera.
With the camera in focus, use the diopter adjustment control to bring the
subject into clear focus in the viewfinder. If necessary, viewfinder focus can be further
adjusted using optional corrective lenses.
D During Charging
Do not move the charger or touch the battery during charging. Failure to observe this
precaution could in very rare instances result in the charger showing that charging is
complete when the battery is only partially charged. Remove and reinsert the battery to
begin charging again.
D Charging the Battery
Read and follow the warnings and cautions on pages x–xi and 218–220 of this manual. Charge
the battery indoors at ambient temperatures of 5 °C–35 °C (41 °F–95 °F). Do not use the
battery at ambient temperatures below 0 °C/32 °F or above 40 °C/104 °F; failure to observe
this precaution could damage the battery or impair its performance. Capacity may be
reduced and charging times may increase at battery temperatures from 0 °C/32 °F to 15 °C/
59 °F and from 45 °C/113 °F to 60 °C/140 °F. The battery will not charge if its temperature is
below 0 °C (32 °F) or above 60 °C (140 °F). If the CHARGE lamp flashes quickly (about eight
times a second) during charging, confirm that the temperature is in the correct range and
then unplug the charger and remove and reinsert the battery. If the problem persists, cease
use immediately and take battery and charger to your retailer or a Nikon-authorized service
representative.
Do not attempt to charge a fully-charged battery. Failure to observe this precaution will
result in reduced battery performance.
Use the charger with compatible batteries only. Unplug when not in use.
AF area brackets

Nikon D5200 Specifications

General

Megapixel	24.1 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	24.71 MP
Image sensor size	- \
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	6000 x 4000
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Continuous Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 6400, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed	1/200 s
Power source type	Battery
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	59.94 fps
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio formats supported	PCM
Internal memory	0 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	921000 pixels
Magnification	0.78 x
Viewfinder type	Optical
USB version	2.0
Product color	Bronze
Scene modes	Beach, Candlelight, Children, Close-up (macro), Dawn, Dusk, Night landscape, Night portrait, Party (indoor), Portrait, Self-portrait, Snow, Sports, Sunrise, Sunset, Landscape (scenery)
Photo effects	Neutral, Vivid
White balance	Auto, Cloudy, Fluorescent, Incandescent, Manual, Shade, Sunny
Shooting modes	Aperture priority, Auto, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL14
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Cables included	AV, USB

Weight and Dimensions

Depth	78 mm
Width	129 mm
Height	98 mm
Weight	555 g
