32
❚❚ Using Optional WR-R10 and WR-T10 Wireless Remote Controllers (0 210)
When a WR-T10 is used in combination with
a WR-R10, the shutter-release button on the
WR-T10 performs the same functions as the
camera shutter-release button, allowing
wireless remote control continuous and
self-timer photography. For more
information, see the manual provided with
the WR-R10/WR-T10.
D Before Using the ML-L3 Remote Control
Before using the ML-L3 for the first time, remove the clear plastic battery-insulator sheet.
D Remote Control Photography
In quick-response (ML-L3) or delayed remote (ML-L3) release mode, the camera responds
only to the shutter-release button on the ML-L3 remote control.
Choose a different release
mode when using WR-R10/WR-T10 wireless remote controllers.
A Cover the Viewfinder
When taking photos without your eye to the
viewfinder, remove the DK-20 rubber eyecup
(q) and insert the supplied DK-5 eyepiece cap
as shown (w).
This prevents light entering via
the viewfinder interfering with exposure.
Hold
the camera firmly when removing the rubber
eyecup.
D Using the Built-in Flash
Before taking a photograph with the flash in P, S, A, M, or 0 mode, press the M (Y) button to
raise the flash and wait for the M indicator to be displayed in the viewfinder (0 23).
Shooting
will be interrupted if the flash is raised while a remote control mode is in effect or after the
self-timer has started.
If the flash is required, the camera will only respond to the ML-L3
shutter-release button once the flash has charged.
In auto, scene, and special effects modes
in which the flash pops up automatically, the flash will begin charging when a remote
control mode is selected; once the flash is charged, it will automatically pop up and fire when
required.
In flash modes that support red-eye reduction, the red-eye reduction lamp will light for
about one second before the shutter is released in quick-response remote mode.
In delayed
remote mode, the self-timer lamp will light for two seconds, followed by the red-eye
reduction lamp which lights for one second before the shutter is released.
A See Also
For information on choosing the duration of the self-timer and the number of shots taken,
see Custom Setting c3 (Self-timer; 0 160).
For information on choosing how long the
camera will wait for a signal from the remote, see Custom Setting c4 (Remote on duration
(ML-L3); 0 161).
For information on controlling the beeps that sound when the self-timer
and remote control are used, see Custom Setting d1 (Beep; 0 161).
WR-R10 WR-T10
DK-20 rubber eyecup DK-5 eyepiece cap
q w
