Page #4 background imageLoading...
Page #4 background image
Standard
Optional
Teleconverter cap BF-3A
Rear lens cap LF-1
Flexible lens pouch CL-S1
Hard lens case CL-30S
Teleconverter cap BF-3A
Rear lens cap LF-1
Flexible lens pouch CL-0715
Teleconverter cap BF-3A
Rear lens cap LF-1
Flexible lens pouch CL-S1
Hard lens case CL-31S
Accessories
TC-14EII TC-17EII TC-20E II
To attach the teleconverter cap: Position the cap in the teleconverter's bayonet mount so that the dot on the
cap is aligned with the teleconverter's mounting index; then turn the cap counterclockwise (with the
teleconverter facing you) until it clicks into place.
TC-14E II
5 elements in 5 groups
Approx. 66mm (2.6 in.) dia. x
24.5mm (1.0 in.) extension
from camera's lens mounting
flange; overall length is
approx. 36.5mm (1.4 in.)
Approx. 200g (7.1 oz.) Approx. 355g (12.5 oz.)
Approx. 66mm (2.6 in.) dia. x
55mm (2.2 in.) extension from
camera's lens mounting
flange; overall length is
approx. 68mm (2.7 in.)
Fully automatic
Via full-aperture method with AI cameras or cameras having a CPU; via stop-down method for
other cameras
Front: Special mount for AF-S/AF-I Nikkor lenses
Rear: Nikon bayonet mount
7 elements in 6 groups
TC-20E II
Lens construction
Dimensions
Weight
Diaphragm
Exposure
measurement
Mount
Approx. 250g (8.8 oz.)
Approx. 66mm (2.6 in.) dia. x
31.5mm (1.2 in.) extension
from camera's lens mounting
flange; overall length is
approx. 43.5mm (1.7 in.)
7 elements in 4 groups
TC-17E II
Focusing
*1 The Nikon N90s, N90, N80-series, N75-series, N70, N65-series and PRONEA 6i are sold exclusively in the
U.S.A.
*2 Both autofocus and manual focus using electronic rangefinder are possible with an AF-S/AF-I Nikkor lens
having maximum aperture of f/4 or brighter with TC-14E II, f/3.36 or brighter with TC-17E II, or f/2.8 or
brighter with TC-20E II.
*3 The Nikon F3AF camera cannot be used.
*4 With TC-14E II, manual focus using electronic rangefinder is possible with an AF-S/AF-I Nikkor lens having
maximum aperture of f/4 or brighter, or maximum aperture of f/2.8 with F-501/N2020*
5
attached. With TC-
17E II, manual focus using electronic rangefinder is possible with an AF-S/AF-I Nikkor lens having maximum
aperture of f/3.36 or brighter, or maximum aperture of f/2.37 with F-501/N2020 attached. With TC-20E II,
manual focus using electronic rangefinder is possible with an AF-S/AF-I Nikkor lens having maximum aperture
of f/2.8 or brighter, or maximum aperture of f/2 with F-501/N2020 attached.
*5 The Nikon N2020 is sold exclusively in the U.S.A. and Canadian markets.
Teleconverter care
Although you should always keep the teleconverter's lens surfaces clean, rough cleaning must be
avoided. Wipe with a soft, clean cotton cloth moistened with alcohol to remove grease or fingerprints
from the lens surfaces.
Be careful not to soil or scratch the teleconverter's lens surface.
Keep both front and rear lens caps in place when you are not using the teleconverter.
If you do not intend to use the teleconverter for a long time, protect it from rust and mold by storing it
in a cool, dry place. Also, do not store it in direct sunlight, and keep it away from naphthalene or
camphor.
Be careful not to get the teleconverter wet or drop it in water. Water may cause it to malfunction.
Specifications
TC-14E II
1.4x that of a prime lens
f/2 ~ f/32 (Effective aperture:
f/2.8 ~ f/45)
1.4x that of a prime lens
1/1.4x that of a prime lens
Same as that of a prime lens
f/2 ~ f/32
(Effective aperture: f/4 ~ f/64)
Double that of a prime lens
1/2x that of a prime lens
Double that of a prime lens
TC-20E II
Focal length
Aperture
coupling range
Reproduction
ratio
Depth of field
Minimum
focusing distance
f/2 ~ f/32 (Effective aperture:
f/3.36 ~ f/53.82)
1.7x that of a prime lens
1/1.7x that of a prime lens
1.7x that of a prime lens
TC-17E II
With a prime lens
Lens’ focus mode
Camera
Camera’s
focus mode
M/A M
F6, F5, F4-series, F100, F90X/N90s*
1
,
Autofocus with Manual focus
F90-series/N90*
1
, F80-series/
C, S, AF
manual priority*
2
(Focus assist is available*
2
)
N80-series*
1
, F75-series/
N75-series*
1
, F70-series/N70*
1
,
F65-series/N65-seires*
1
,
PRONEA600i/6i*
1
, PRONEA S,
M Manual focus only (Focus assist is available*
2
)
D2-series, D1-series, D100,
D70-series, D50
Other AF (autofocus ) cameras
(except for F3AF*
3
)
C, S, AF, M Manual focus only (Focus assist is available*
4
)
Other Nikon cameras Manual focus only
