Niles IntelliPad Ci User Manual

I NTELLI P AD
®
C I K EYPAD M ODULES
8
Figure 5
(a) Electrical box (J-box)
(b) Four pair twisted cable
(c) Solo Master Keypad Module
(d) Numeric Accessory Keypad Module
(e) Master Keys
(f) Function Keys
(g) Device screws (4 supplied)
(h) Solo Master Keypad Module
Decora style insert
(i) Numeric Accessory Keypad Module
Decora style insert
(j) Decora two-gang faceplate (not supplied)
(k) Faceplate screws (not supplied)
a
b
c
d
e
f
g
h
i
j
k
