Service / Repair.
Dismounting of cabinet rear part on following variants:
C 125.7 - C 125.7 X-TRA
1. Tools: Screwdriver PH2
2. Remove the 2 screws (Long) fixing the handle (fig. 3)
3. Remove the 6 screws (Short) from the rear side (fig. 4)
4. Don’t remove the accessory bracket
5. Remove the wheels and remove the 2 screws behind the wheel parts (fig. 5)
6. The cabinet rear part can be removed and there is now access to the motor pump unit
Fig. 3
Fig. 4
Fig. 5
Long screws
Short screws
