Nilfisk-Advance C 100.7 Repair Manual

17
D
Service / Repair.
Assembly of cabinet rear part on following variants:
C 100.7 / C 105.7 / C 110.7 / C 120.7 / C 120.7 X-TRA
1. Tools: Screwdriver PH2
2. Mount the 6 short screws from the rear side (fig. 3)
3. Mount the handle and the 2 long screws to fix the handle
Fig. 1
Fig. 2
Xx/yy mm
Xx/yy mm
