Nilfisk-Advance C 110.3 - Main Technical Data; Model-Specific Data

14
Declaration
Manufacturer's name and address or his
authorized representative in the Community
Nilfi sk-Advance A/S
Industrikvarteret
9560 Hadsund
Denmark
Name of the person responsible for the
technical documentation
Anton Sørensen, General Manager of Technical Operations EAPC
Description of the equipment:
Equipment name
Model
Rated output voltage
Rated frequency
High pressure washer
Nilfi sk
C 100.5-5 / C 110.3-5 / C 110.3-5 X-TRA
AC 230-240 V
50 Hz
Measured sound pressure level
78 dB(A)
Guaranteed sound power level
93 dB(A)
Declaration
The equipment refer in this document fulfi ls all the requirements of
the Directive :
Machine Directive 2006/42/EC
Low-voltage Directive 2006/95/EEC
EMC Directive 2004/108/EEC
Outdoor Noise Directive 2000/14/EC
EN ISO 12100-1, EN ISO 12100-2, EN 60335-2-79
EN 55014-1 (2006), EN 55014-2 (2001), EN 61000-3-2 (2006)
Place and date of the declaration
Hadsund, September 1, 2008
Signature
9 Main Technical Data
Type C 100.5-5 C 110.3-5 C 110.3-5 X-TRA
Rated pressure
bar/
MPa
70/7.0 75/7.5 75/7.5
Permissible pressure
bar/
MPa
max. 100/10.0 max. 110/11.0 max. 110/11.0
Rated flow l/min 5.3 5.2 5.2
Rated input kW 1.3 1.4 1.4
Rated voltage V 230-240 230-240 230-240
Max. water temperature °C 40 40 40
Inlet pressure
bar/
MPa
0.15-10/0.015-1.0 0.15-10/0.015-1.0 0.15-10/0.015-1.0
Sound pressure level dB(A) 78 78 78
Guaranteed sound power level dB(A) 93 93 93
Vibration according to ISO 5349 m/s
2
max. 2.5 max. 2.5 max. 2.5
10 Declaration
