D
Service / Repair.
Fig.2
Fig.3
Dismount / Mounting of Motor cover.
Remove 4 torx (TX20) screws . (fig.1 ) When mounting the motor cover
and front chassis be sure that the wire are in the right position. (fig.2 and 3)
Fig.1
