Nilfisk-Advance C 125.7 Repair Manual

12
D
Service / Repair.
Fig. 1
Dismounting / mounting of the start / stop valve.
Fig 1 is showing how the start / stop valve must be assembled.
A special tool is needed in order to take out the seat of the start / stop valve (fig 2)
Please use “Puller for valve seat M4” item number 31000189.
NOTE: the valve seat is no longer usable after using the puller.
Fig. 2

Nilfisk-Advance C 125.7 Specifications

General

Max Pressure	125 bar
Max Flow Rate	460 L/h
Water Flow Rate Qiec	320 L/h
Water Flow	460 L/h
Weight	6.6 kg
Hose Length	5 m
Max. Inlet Temperature	40°C
Voltage	230 V
Frequency	50 Hz
Power Consumption	1500 W
