Construction
C
SM MC 3C_ MC 4M Ver.1.0_March 2015
37
MC 3C
MC 4M
Lid f. oil container
Oil container
Micro switch
Unloader
Water outlet
Motor
NA3 pump
Water inlet
Motor
NA4 pump
Water inlet
Lid f. oil container
Oil container
Unloader
Micro switch
Water outlet conection
for hose reel
