Nilfisk-ALTO NEPTUNE E - Specifications; Guarantee; Technical Data; EU Declaration of Conformity

16
english
1)
Accessories / model variants
NEPTUNE E
9.2 Guarantee
Our general conditions of busi-
ness are applicable with regard
to the guarantee. Subject to
change as a result of technical
advances.
The guarantee is invalidated if the
machine is not operated in ac-
cordance with these instructions
or otherwise abused. The guaran-
tee is invalidated if the machine is
not serviced as described.
NEPTUNE
E 12 E24
Voltage 400 V / 3~/ 50Hz
EU EU
Fuse (slow)
A25 50
Power rating
kW 16 28
Heating
kW 12 24
Working pressure
bar/MPa 150/15
Permissible pressure
bar/MPa 250/25
Volume flow (max)
l/h 750
Volume flow Q
IEC
l/h 720
Permissible temperature
°C 80
Max. water inlet temperature
°C 70
Max. water inlet pressure
bar/MPa 10/1
Dimensions l x w x h
mm 1150 x 702 x 987
Weight
kg 131,5 134,5
Noise level at a distance of 1 m EN
60704-1
dB(A) 70,4
Sound power level LW
A
dB(A) 85,4
Vibration
m/s² <2,5
Recoil forces
N36
Boiler
l74
Detergent tank A / B
l 35 / 10
Oil quantity
l 1,0
Oil type
SAE 15W-40
9.3 Technical data
9.4 EU Declaration of
Conformity
EU Declaration of Conformity
Product:
High Pressure Cleaner
Type:
NEPTUNE E
Description:
400 V 3~, 50 Hz, IP X5
The design of the unit corresponds to the
following pertinent regulations:
EC Machine Directive 98/37/EC
EC Low-voltage Directive 73/23/EC
EC EMC Directive 2004/108/EC
Applied harmonised standards:
EN 12100-1, EN 12100-2, EN 60335-2-79
EN 55014-1, EN 55014-2, EN 61000-3-2
Applied national standards and technical
specifications:
DIN EN 60335-2-79
ALTO Deutschland GmbH
Guido-Oberdorfer-Straße 2-8
D-89287 Bellenberg
Dipl. Ing. Wolfgang Nieuwkamp
Tests and approvals Bellenberg, 18.04.2005
