www.Ninjapaintball.com
SETTING UP THE NINJA PCP FILL ADAPTER
Your fill adapter is equipped with a standard “UFA” fitting on the input side. This
fitting will connect to any Ninja high pressure regulator.
On the backside of the fill station is a vent port.
▲ FOR SAFETY REASONS, THE VENT PORT #7 MUST BE
DIRECTED AWAY FROM THE OPERATOR AND BYSTANDERS.
This port is equipped with 1/8 NPT threads so that if desired, a vent hose or
muffler may be attached.
Do not over tighten the vent knob as this may damage the
seal. Only turn the knob enough to stop the release of gas.
▲ ALL HOSE, FITTINGS, AND MUFFLERS MUST HAVE A
MINIMUM WORKING PRESSURE OF 3000 PSI. Do not use a
bronze sintered muffler!!
▲ Never operate the PCP Fill Adapter unless a PCP AIR RIFLE is
attached to the fill adapter on the end of the fill hose. Operating
the PCP Fill Adapter without a PCP AIR RIFLE attached will
cause the fill hose to “whip”. Injury may result!!
Date: February 2013
WARNING: Compressed air will rush out of the vent station hole (part #7) when
relieving pressure from the fill hose. Use caution in directing the venting air.
ALWAYS WEAR GLOVES AND SAFETY GLASSES WHEN OPERATING THIS
FILL STATION!!
WARNING: Do NOT disconnect the hose under pressure. Disconnecting the hose
under pressure could cause damage to the hose fitting and personal injury to the
operator.
