www.Ninjapaintball.com
1.5 Once attached do not let the fill station, air system or rifle hang by any component. Support the fill
station, rifle and air system.
1.6 Open the valve slowly by turning the UFA knob (part# 2) in a clockwise direction. You should
hear the air gun filling with air. A complete fill should take no more than approximately 10
seconds. Fill the air gun to manufacturer recommendation.
1.7 Check the air gun pressure gauge. The gauge should read a pressure equal to the output pressure of
the bottle regulator pressure you are filling from, typically 3000 psi. Do not over pressurize the
rifle, check the rifle owner’s manual for the correct pressure.
1.8 Upon Completion of filling, turn the UFA knob (part # 2) in a counter-clockwise direction until it
stops.
1.9 Bleed the pressure from the fill hose by turning the vent station knob (part # 5) slowly in a
counter-clockwise direction.
1.10 Disconnect the quick disconnect from the gun, if it does not open easily insure the fill station
is vented and no air is in the fill station.
1.11 Disconnect the UFA from the High Pressure Air bottle regulator.
3.0 Maintenance and Care of the Ninja PCP Fill Adapter
Keep the Fill Adapter clean and dry.
Periodically check the fill adapter and fill hose for thread integrity, cracks or other wear
replace any suspect part immediately for assistance call 877-646-5287
www.ninjapaintball.com
Date: February 2013
WARNING: Do NOT disconnect the hose under pressure. Disconnecting the
hose under pressure could cause damage to the hose fitting and personal
injury to the operator.
WARNING: Compressed air will rush out of the vent station hole (part #7)
when relieving pressure from the fill hose. Use caution in directing the venting
air. ALWAYS WEAR GLOVES AND SAFETY GLASSES WHEN
OPERATING THIS FILL STATION!!
