Nintendo Switch Manual

3
y!aPl
3. Play!
1. Connect the AC adapter
2. Set up the console
There are two types of Nintendo Switch software:
a retail version, which includes a game card that
you insert into the console, and a downloadable
version that you download and save to the
console or a microSD card.
Here is a brief introduction to playing a game,
using the retail version as an example.
Changing your settings
Open the game card slot and insert the game card.
Pay careful attention to the direction the game
card is facing when you insert it.
Make sure that the label on the game card is
facing you, then insert it into the game card slot
until you hear a click.
The software icon for the inserted game card will
appear on the HOME Menu. Select the icon with
your cursor, then press the A Button to start the
software.
Play!

Nintendo Switch Specifications

General

Platform	Nintendo Switch
Accelerometer	Yes
Internal memory	4096 MB
Processor cores	8
Processor frequency	768 MHz
Product color	Blue, Grey, Red
Built-in touchpad	No
Gaming control technology	Analogue / Digital
Gaming control function buttons	D-pad
Display diagonal	6.2 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Built-in memory capacity	32 GB
Maximum memory card size	2000 GB
Frequency band	2.4/5 GHz
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
Headphone outputs	1
USB connector type	USB Type-A, USB Type-C
Headphone connectivity	3.5 mm
Number of built-in speakers	2
Charging time	3 h
Battery capacity	4310 mAh
Battery life (max)	6.5 h
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, HDMI

Weight and Dimensions

Depth	14 mm
Width	239 mm
Height	102 mm
Weight	297 g
