6
Support Information
Nintendo Customer Support (UK and Ireland) [190421/UKV]
Nintendo Customer Support
https://support.nintendo.co.uk
If, having inspected the Product, Nintendo accepts that the Product is defective, Nintendo will (at its
sole discretion) either repair or replace the part causing the defect, or replace the relevant element
of the Product without charge.
If the above 24-month warranty period has expired at the time the defect is notified to Nintendo or
if the defect is not covered by this warranty, Nintendo may still be prepared to repair or replace the
part causing the defect or replace the relevant element of the Product (at its sole discretion). For
further information or, in particular, details of any charges for such services, please contact Nintendo
Customer Support.
This manufacturer′s warranty does not affect any statutory rights which you may have under
consumer protection legislation as the purchaser of goods. The benefits described here are in
addition to those rights.
Nintendo Switch
Operating frequency band(s) Maximum radio-frequency power
Bluetooth
®
2402-2480MHz 3dBm
WLAN
2412-2472MHz / 5180-5320MHz
(indoor use only)* / 5500-5700MHz
19dBm / 15dBm / 15dBm
Nintendo Switch –
OLED Model
Operating frequency band(s) Maximum radio-frequency power
Bluetooth
®
2402-2480MHz 2dBm
WLAN
2412-2472MHz / 5180-5320MHz
(indoor use only)* / 5500-5700MHz
15dBm / 7.5dBm / 7.5dBm
Joy-Con (L)
Operating frequency band(s) Maximum radio-frequency power
Bluetooth 2402-2480MHz 4dBm
Joy-Con (R)
Operating frequency
band(s)
Maximum
radio-frequency power
Maximum
eld strength
Bluetooth 2402-2480MHz 4dBm
NFC 13.56MHz -6dBµA/m
Nintendo Switch Lite
Operating frequency
band(s)
Maximum
radio-frequency power
Maximum
eld strength
Bluetooth 2402-2480MHz 2dBm
WLAN
2412-2472MHz / 5180-
5320MHz (indoor use
only)* / 5500-5700MHz
19dBm / 15dBm / 15dBm
NFC 13.56MHz -1dBµA/m
Technical Specications
Ecodesign Information for the Nintendo Switch AC Adapter
Commercial registration number of EU authorised
representative
HRB 101840
Model identifier HAC-002(UKV)
Input voltage AC 100-240V
Input AC frequency 50/60Hz
Output voltage * DC 5.0V DC 15.0V
Output current 1.5A 2.6A
Output power 7.5W 39.0W
Average active efficiency 76.8% 88.5%
Efficiency at low load (10%) 83.0%
No-load power consumption 0.08W 0.08W
*
The AC Adapter (HAC-002(UKV)) has two types of DC output power, and the output voltage is automatically changed depending on
the connected device.
Console Ecodesign Information
Information concerning this product’s energy consumption, power management and resource eciency is
available at https://nintendo-europe.com/switch-ecodesign
For explanation of the symbols and markings used on this product, see http://docs.nintendo-europe.com
DECLARATION OF CONFORMITY
Hereby, Nintendo declares that the radio equipment type (Nintendo Switch/Nintendo Switch – OLED Model/
Nintendo Switch Lite/Joy-Con) is in compliance with Directive 2014/53/EU. The full text of the EU declaration of
conformity is available at the following internet address: http://docs.nintendo-europe.com
For UK: Hereby, Nintendo declares that the radio equipment type (Nintendo Switch/Nintendo Switch – OLED Model/
Nintendo Switch Lite/Joy-Con) is in compliance with the relevant statutory requirements. The full text of the
declaration of conformity is available at the following internet address: http://docs.nintendo-europe.com
The Bluetooth
®
word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Nintendo
is under license. Other trademarks and trade names are those of their respective owners.
© Nintendo.
Trademarks are property of their respective owners. Nintendo Switch and Joy-Con are trademarks of Nintendo.
* This restriction applies in the following countries:
Belgium (BE), Bulgaria (BG), Czech Republic (CZ), Denmark (DK), Germany (DE),
Estonia (EE), Ireland (IE), Greece (EL), Spain (ES), France (FR), Croatia (HR),
Italy (IT), Cyprus (CY), Latvia (LV), Lithuania (LT), Luxembourg (LU),
Hungary (HU), Malta (MT), Netherlands (NL), Austria (AT), Poland (PL),
Portugal (PT), Romania (RO), Slovenia (SI), Slovakia (SK), Finland (FI),
Sweden (SE), Switzerland (CH) and United Kingdom (Northern Ireland) (UK(NI)).

Other manuals for Nintendo Switch

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Nintendo Switch and is the answer not in the manual?

Nintendo Switch Specifications

General IconGeneral
PlatformNintendo Switch
AccelerometerYes
Internal memory4096 MB
Processor cores8
Processor frequency768 MHz
Product colorBlue, Grey, Red
Built-in touchpadNo
Gaming control technologyAnalogue / Digital
Gaming control function buttonsD-pad
Display diagonal6.2 \
Touch technologyMulti-touch
Touchscreen typeCapacitive
Display resolution1280 x 720 pixels
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Built-in memory capacity32 GB
Maximum memory card size2000 GB
Frequency band2.4/5 GHz
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.1
Headphone outputs1
USB connector typeUSB Type-A, USB Type-C
Headphone connectivity3.5 mm
Number of built-in speakers2
Charging time3 h
Battery capacity4310 mAh
Battery life (max)6.5 h
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)20 - 80 %
Cables includedAC, HDMI
Weight and Dimensions IconWeight and Dimensions
Depth14 mm
Width239 mm
Height102 mm
Weight297 g
