Adjust the air flow direction of ventilators. Open or close, and adjust the air flow direction
of ventilators.
: This symbol indicates that the vents
are closed when the vent switch is
moved to the left.
: This symbol indicates that the vents
are open when the vent switch is
moved to the right.
SAA0373 SAA0374
VENTILATORS
4-2 Heater, air conditioner and audio systems
